FILM BLOWING MACHINE
Chinese Quality Rotary Die head Film Blowing MachineChinese Quality Rotary Die head Film Blowing Machine

Chinese Quality Rotary Die head Film Blowing Machine



Model: SJ/MC

Mob: 0086 13587581245
Tel: 0086-577-65518833
Fax: 0086-577-65518833
Email: sale@chinatplast.com

Chinese Quality Rotary Die head Film Blowing Machine



Model: SJ/MC
PRODUCT INFORMATION

Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitriding, So it is sound in hardness, durable in corrosion resistance.

The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones



Main Technical Variables:


<-------- Can Move Left or Right -------->

 Model

SJ-50/MC600

SJ-55/MC800

SJ-60/MC1000

SJ-65/MC1200

 Screw Diameter (mm)

Φ50

Φ55

Φ60

Φ65

Screw Length (L/D)

28:1

28:1

28:1

28:1

 Film Width(mm)

200-600

300-800

400-1000

600-1200

 Film Thickness(mm)

0.006-0.10

0.006-0.10

0.006-0.10

0.006-0.10

 Max.Extrusion Output (kg/h)

45

55

60

70

 Die Size(mm)

Φ60/100

Φ80/150

Φ100/200

Φ120/250

 Cylinder Cooling (Kw)

0.25

0.25X2

0.25X2

0.25X3

 Driving Motor(kw)

11

15

18.5

22

Total power(kw)

28

36

42

48

 Cover Dimension(m)

5.0*2.1*4.5

5.0*2.3*4.8

5.5*3.3*5.5

5.8*3.6*6

Weight of Machine(kg)

1500kg

2000

2300

2600



We are Chinese Quality Rotary Die head Film Blowing Machine suppliers/manufacturers from china factory . We also can produce the Chinese Quality Rotary Die head Film Blowing Machine according to the client’s requirement. We are always try our best to become the good Chinese Quality Rotary Die head Film Blowing Machine, film blowing machine, pe film blowing machine, rotary die head film blowing machine, plastic film blowing machine, high speed film blowing machine manufacturers/suppliers and welcome the customer from all over the world to contact with us.
