Use:
This machine set is used for blowing Low-density polyethylene(LDPE)and high-density polyethyene(HDPE)plastic film to make various vest bags and flat-rim bags which have been widely used for packing in the food industry,gamenet industry and textile industry,etc.
Model | SJ-65FM-600 | SJ-70FM-800 |
Screw Diameter | 65mm | 70mm |
Screw Ratio | 1:28 | 1:28 |
Screw Speed | 10-110r/min | 10-110r/min |
Max.Output | 50kg/h | 65kg/h |
Max.Folding Width of Film | 600mm×2 | 800mm×2 |
Single-sided Thickness of Film | 0.006-0.10mm | 0.006-0.10mm |
Power of Main Motor | 22Kw | 30Kw |
Total Power | 26Kw | 40Kw |
Weight of Machine | 3000kg | 4500kg |
Overall Dimensions | 4800×2200×3800 | 5200×2600×4200 |
